Qhov sib txawv ntawm Flap Discs thiab Sib Tsoo Discs

Hauv kev ua haujlwm hlau, xaiv cov cuab yeej zoo abrasive feem ntau yog qhov tseem ceeb tshaj qhov kev xaiv lub cuab yeej fais fab nws tus kheej. Yog tias koj tau siv cov hlau sib tsoo disc los tiv thaiv cov welds nyuaj los yog npaj cov hlau nto rau kev pleev xim, koj yuav nkag siab tias yuav muaj qhov sib txawv loj ntawm cov khoom siv abrasive ntawm lub cuab yeej thiab qhov xav tau ntawm cov haujlwm tshwj xeeb.



Kab lus no qhia meej qhov sib txawv ntawm flap discs thiab sib tsoo discs. Ob qho abrasives no feem ntau yuam kev xav tias yuav hloov pauv tau, tab sis lawv cov kev siv sib txawv heev. Xaiv qhov tsis ncaj ncees lawm abrasive tuaj yeem cuam tshuam rau txhua yam ntawm kev txiav ceev thiab kev pheej hmoo ntawm khawb mus rau qhov chaw tiav, tsim hluav taws xob, thiab thaum kawg, tus neeg teb xov tooj qaug zog.



Cov qauv sib txawv: Yuav ua li cas Txhua Disc tsim (thiab Vim Li Cas Nws Tseem Ceeb)



Qhov sib txawv tseem ceeb ntawm kev sib tsoo discs thiab nrov plig plawg disc yog nyob rau hauv lawv cov qauv tsim. Qhov sib txawv ntawm lub cev no hais txog lawv txoj haujlwm, kev nyab xeeb kev ua haujlwm, thiab tsim nyog rau kev ua haujlwm siab - nrawm ntawm ib qho chaw ua haujlwm.



Sib tsoo log



A sib tsoo loglos yog disc yog cov cuab yeej sib koom ua ke, qhov twg cov khoom abrasive (xws li txhuas oxide) tau sib koom ua ke los ntawm cov resin los yog fiberglass binder los tsim cov matrix nruj. Cov log sib tsoo muaj qhov tuab, cov khoom siv (feem ntau 1/4 nti lossis tuab dua), muab kev nruj zoo heev.





Qhov rigidity no tso cai rau kev sib tsoo log siv rau lub workpiece nrog siab heev. Lawv ua tau zoo ntawm qhov hnyav - lub luag haujlwm sib tsoo, chamfering, thiab tshem tawm cov khoom loj heev. Hlau sib tsoo lub log yog qhov kev xaiv zoo tshaj plaws thaum cov kws tshaj lij yuav tsum txiav cov vuam loj, zoo li cov hlau cam khwb cia, los yog ceev nrooj tawv nyom nyom nyom. Lawv qhov chaw sib cuag loj dua thiab tuab tso cai rau kev sib sib zog nqus, txawm tias txiav cov hlau zoo li stainless hlau thiab carbon hlau, tshem tawm cov khoom zoo.



Flap Disc



Flap disc yog txheej txheej abrasive. Nws muaj ntau tus neeg abrasive flaps teem radially nyob ib ncig ntawm lub hauv paus hub, mus tas li txuas mus rau lub phaj rov qab.



Raws li cov flaps hnav, cov khoom siv abrasive tshiab txuas ntxiv nthuav tawm los ntawm txheej. Qhov no tus kheej txuas ntxiv no -ntxhiab qhov kev txiav txim thiab segmented contact nto tso cai rau nrov plig plawg discs muab ib tug smoother txiav, ib tug ntau yam ntawm nto tiav, thiab qis suab nrov. Vim hais tias qhov kev sib cuag siab tau muab faib thoob plaws ntau yam abrasive flaps es tsis yog concentrated ntawm ib qho khoom nto, txiav cov qhab nia raug txo, thiab cov cua sov concentration hauv ib cheeb tsam yog tsawg, ua rau nws xaiv zoo dua rau kev sib tsoo thiab polishing ntawm workpieces. Nws qhov yooj yim hauv paus kuj ua rau nws nyiam cov cuab yeej rau cov neeg tsim riam rau contouring thiab sib tsoo.



Sib tsoo log vs. Flap Discs: Kev ua tau zoo sib txawv cuam tshuam rau kev sib tsoo



Qhov sib txawv ntawm kev tsim kho ua rau muaj kev ua tau zoo sib txawv. Xaiv cov cuab yeej tsim nyog txhais tau tias ua kom lub sijhawm ua haujlwm tau zoo thiab ua tiav qhov kev xav tau zaum kawg yam tsis muaj qhov tsim nyog rov ua haujlwm.



Khoom tshem tawm tus nqi (Xaiv: Sib Tsoo Log)



Rau kev tshem tawm cov khoom ntxhib, tawv, lub log sib tsoo yog qhov kev xaiv zoo tshaj plaws. Tsim los rau kev tshem tawm cov khoom siv ntau tshaj plaws, nws yog qhov tseem ceeb rau hnyav- lub luag haujlwm sib tsoo, loj- lub kaum sab xis, thiab sib tsoo loj welds. Kev tsim kho zoo ntawm kev sib tsoo lub log tso cai rau tus neeg teb xov tooj siv lub zog siab rau lub cuab yeej.



Qhov no muaj peev xwm tshem tawm cov khoom loj loj ua rau kev sib tsoo log zoo tagnrho rau kev tshem tawm cov hlau hnyav thiab ua cov hlau tuab hauv kev tsim khoom. Sib tsoo lub log yog tsim los rau lub hom phiaj tshwj xeeb no: ceev tshaj qhov chaw tiav.



Blending thiab Smoothing (Xaiv: Flap Disc)



Rau tej yaam num uas yuav tsum tau ib tug du, uniform nto, flap disc yog qhov zoo tshaj plaws kev xaiv. Lub overlapping abrasive flaps zoo tshaj plaws ntawm kev sib tov sib xyaw, xeb tshem tawm, thiab contouring. Ntawm cov npoo nkhaus lossis cov tubing, nrov plig plawg discs ua tau zoo dua li kev sib tsoo lub log, uas ua rau muaj qhov ua tiav ntau dua. Rau cov dej num uas yuav tsum tau tshem tawm ntawm cov khawb khawb sab laug los ntawm kev sib tsoo lub log, lossis kom ua tiav cov kev hloov pauv zoo dua yam tsis hloov cov cuab yeej (piv txwv li, mus rau nrov plig plawg disc), nrov plig plawg disc yog qhov kev xaiv zoo tshaj plaws. Qhov no yog qhov tseem ceeb rau kev sib tsoo zoo tshaj plaws.



Thaum tshav kub kub Generation thiab Operator Control



Thaum ua hauj lwm ntawm cov hlau nto, lub tshav kub yog ib qho kev txhawj xeeb loj, vim nws tuaj yeem ua rau deformation lossis tsis pom qhov kub hnyiab (blue / discoloration).

Qhov sib xyaw ua ke, siab - kev sib txhuam qhov chaw ntawm lub log sib tsoo ua rau kom muaj cua sov sai. Conversely, flap discs dissipate tshav kub ntau npaum. Lawv segmented tsim thiab cov nyhuv txias ntawm airflow ntawm lub abrasive flaps ho txo ​​qhov chaw kub tsub zuj zuj. Qhov no kuj txhais ncaj qha rau hauv kev tswj cov cuab yeej smoother. Flap discs muaj kev sib cuag nrog lub workpiece, txo kev ncaws pob thiab yog li tus neeg ua haujlwm qaug zog. Qhov sib txawv no yog qhov tseem ceeb rau kev ua haujlwm tshwj xeeb ntawm cov khoom nyias, tiaj tus.



Kev pab lub neej thiab hnav qauv



Lub neej kev pab cuam ntawm ob hom ntawm cov cuab yeej abrasive feem ntau underestimated.



Sib tsoo lub log tuav ib qho profile thiab txiav quab yuam kom txog thaum lawv hnav mus rau lub hub. Lawv tshem tawm cov khoom zoo, tab sis yuav tsum tau hloov thaum lub log loj dhau los ua me me lossis thaum hnav tsis sib xws ntawm ntug sab hauv.



Abrasive daim ntaub log muaj lub neej ua haujlwm ntev dua ntawm kev siv cov khoom siv. Lawv hnav maj mam, tsis tu ncua nthuav tawm cov txheej tshiab ntawm cov khoom siv abrasive. Qhov no ua kom cov ntaub abrasive log tswj nws qhov ntse thiab du nto tiav nyob rau lub sijhawm ntev. Yog li ntawd, nyob rau hauv lub sij hawm ntev, ntev li ntev raws li loj npaum li cas ntawm cov ntaub ntawv tshem tawm uas yuav tsum tau ib tug sib tsoo log tsis muaj kev koom tes, abrasive daim ntaub log feem ntau yog ib tug ntau yig thiab haum abrasive cuab tam.
